Mounted Disc Plough (Tubular Frame)
Heavy Duty Mounted Cum Trailed Offset Disc Harrow (Compact Model)
Heavy Duty Trailed Offset Disc Harrow
Heavy Duty Spring Loaded Cultivator
Heavy Duty Rigid Type Cultivator
Hydraulically Reversible MB Plough
Hydraulic Tipping Trailer (Double Axle / 4 Wheels)
Terracer Blade or Land Leveller
Lawn Mower, Rotary Slasher, Grass Cutter, Stub Cutter
Mobile Water Tankers (10000 Ltrs)
Tractor Crane with Hydraulic Electric Pole Erection Machine
Tractor Crane with Hydraulic Post Hole Digger (Pillar / Pole Lifter)
Tractor Front Loader and Back Hoe
| NO.OF TINES | 9 | 11 | 13 |
| HITCH TYPE | Category l & II | Category l & ll | Category l & ll |
| OVERALL WIDTH (INCH) | 72" | 87" | 102" |
| SEEDING WIDTH (ROW SEEDING) (INCH) |
67" | 82" | 97" |
| TYPES OF TINE | Shovel Type | ||
| ROW SPACING (INCH) | 7.5" | ||
| SEED CAPACITY | 50 Kg. | 80 Kg. | 100 Kg. |
| FERTILIZER CAPACITY | 50 Kg. | 80 Kg. | 100 Kg. |
| SEED METERING DEVICE | Nylon Type Fluted Roller | ||
| FERTILIZER METERING DEVICE | Nylon Type Fluted Roller | ||
| METERING DEVICE DRIVE | Metering Device Drive is from front mounted ground wheel chain | ||
| GROUND WHEEL | One 15 inch diameter spiked roller with spring to maintain contact with ground. 1 , | ||
| SEED DRILLING DEPTH (INCH) | 50 mm to 100 mm | ||
| APPROX WEIGHT | 310 Kg. | 360 Kg. | 410 Kg. |
©
